Source: Source not recorded
Portland, Oregon
Sixth Church of Christ, Scientist
Austin Organs, Inc., Opus 1797, 1931
Austin Organs, Inc., Opus 1797A, 1986 - Tonal Revision
GREAT (Expressive * )
8 Principal 61
8 Second Open Diapason 61 (*)
8 Bourdon 61 (*)
8 Viol d'Amour 61 (*)
4 Octave 61
4 Nachthorn 61 (*)
2 Fifteenth 61
IV Fourniture [19-22-26-29] 244
8 Harmonic Tuba 61 (*)
Chimes (25)
Great 16'
Great Unison Off
Great 4'
1 blank stoptablet
SWELL (Expressive)
16 Bourdon 73
8 Open Diapason 73
8 Stopped Diapason 12 Bour.
8 Quintadena 73
8 Salicional 73
8 Voix Celeste (tc) 61
4 Flute d'Amour 12 Bour.
8 Harmonic Cornopean 73
8 Oboe 73
8 Vox Humana 73
Tremolo
Swell 16'
Swell Unison Off
Swell 4'
1 blank stoptablet
CHOIR (Expressive)
8 Violin Diapason 73
8 Concert Flute 73
8 Flute Celeste (tc) 61
8 Dulciana 73
4 Orchestral Flute 73
8 Clarinet 73
Tremolo
Chimes (Gt) --
Choir 16'
Choir Unison Off
Choir 4'
1 blank stoptablet
PEDAL
16 Open Diapason 32 wood.
16 Bourdon 32
16 Lieblich Gedeckt (Sw) --
16 Double Dulciana (Ch) 12
8 Principal 32
8 Flute (Ch) --
4 Super Octave 12
III Mixture [15-19-22] 96
16 Posaune 32
1 blank stoptablet
COUPLERS
Swell to Pedal 8,4
Great to Pedal 8,4
Choir to Pedal 8,4
Swell to Great 16,8,4
Choir to Great 16,8,4
Swell to Choir 16,8,4
FINGER PISTONS
General 1 - 14
Swell 1 - 8
Great 1 - 8
Choir 1 - 8
Cancel
Master Swell Pedal On/Off
TOE STUDS
General 1 - 6
Pedal 1 - 4
Ped [Gt. to Ped.] (rev)
Sforz (rev)
PEDAL MOVEMENTS
Swell Expression (bal.)
Great Expression (bal.)
Choir Expression (bal.)
Crescendo (bal.)
ACTION: E-P - Austin Universal Windchests ™
VOICES: 28
STOPS: 36; inc. chimes
RANKS: 33
PIPES: 1,990
NOTES
At the time of the rebuild in 1986, a new, unenclosed Great chest was
added to hold the new 4-stop Principal chorus (8, 4, 2, IV). The original
Great chest was left enclosed and expressive; however, some tonal changes
were made. The original 8' First Open Diapason was removed, and a new 8'
Bourdon substituted in its place. The original 8' Claribella Flute was
also removed and a new 4' Nachthorn put in its place. The original 4'
Wald Flute was also removed, but without substitution.
The Pedal division was augmented by adding a new principal unit at 8' and
4' on a new chest. Also new to the Pedal were the III Mixture and the 16'
Posaune on new chests.
Additional work included a rebuilding of the console combination action
at the factory to better suit the new specifications. A new rectifier was
provided. All new action units were installed. The three expression
engines were factory rebuilt, and the main regulator was rebuilt. Tonal
finishers spent one week regulating the old pipes.
The Swell 8' Vox Humana is on its own chest and has a separate tremolo
which is automatically activated when the stop is registered.
[Received on line from James R. Stettner April 20, 2009.]Source: Source not recorded
