M. P. Möller Opus 9861 (1963)

Zion Lutheran Church
143 Albany Street & Woodward Drive
Ferndale, MI

Images

2024-01-09 - Blower nameplate 1-1/2 Horsepower Style 3-P-2724 1150 RPM (Photograph by Roman Lizak/Roman Lizak)

2024-01-09 - Kinetic Blower (Photograph by Roman Lizak/Roman Lizak)

2024-01-09 - Swell pipework (Photograph by Roman Lizak/Roman Lizak)

2024-01-09 - Great pipework (Photograph by Roman Lizak/Roman Lizak)

2024-01-09 - Builder’s nameplate (Photograph by Roman Lizak/Roman Lizak)

2024-01-09 - Console (Photograph by Roman Lizak/Roman Lizak)

Consoles

Main

Organ type: Traditional With Roll Top
Console position: Console in Fixed Position, Center
2 manuals
13 stops
17 registers
3 divisions
Key action Type: Electrical
Stop action Type: Electrical
Stop layout Type: Tilting/Rocking Tablets Above Top Manual
Manual compass: 61 notes
Pedal compass: 32 notes
Pedal Type: Concave Radiating (Meeting AGO Standards)
Expression Type: Balanced Expression Shoes/Pedals (Meeting AGO Standards)
Combination action: Adjustable Combination Pistons
Has combination thumb pistons
Has coupler toe pistons
Has tutti thumb pistons
Has tutti toe pistons

Notes

2009-01-05 - Identified from factory documents and publications courtesy of Stephen Schnurr. -Database Manager

2009-07-13 - Updated through online information from Jeff Scofield. -Database Manager

2011-05-01 - Updated through online information from Connor Annable. -Database Manager

Stoplist

Stoplist copied from the factory specifications Source: Source not recorded Date not recorded

    Ferndale, Michigan
    Zion Lutheran Church

    Möller   Op. 9861   1963   2/14

    GREAT (encl)          SWELL                       PEDAL
 8' Principal 61       8' Gedeckt 61              16' Contrebasse 32 *
 8' Rohrflöte 61       8' Gemshorn 61             16' Bourdon 12 GT
 4' Octave 61          8' Gemshorn Celeste 49 tc   8' Geigen Principal 12
 2' Fifteenth 61       4' Nachthorn 61             8' Bourdon GT
II  Mixture 122        2' Principal 61             4' Octave 12
    Tremulant      1 1/3' Larigot 61
                       8' Trumpet 61               *  1-12 wood
                          Tremulant
                          Sub
                          Unison off
                          Super

[Received on line from Jeff Scofield July 13, 2009.]

Documents

(1963-05-26) Factory Documentation Factory Documentation courtesy of the OHS Archive -Roman Lizak
