M. P. Möller Opus 10396 (1968)

Consoles

Main

• Organ type: Traditional With Roll Top
• 2 manuals
• 26 stops
• 7 registers
• 3 divisions
• Key action Type: Electrical
• Stop action Type: Electrical
• Stop layout Type: Tilting/Rocking Tablets Above Top Manual
• Manual compass: 61 notes
• Pedal compass: 32 notes
• Pedal Type: Concave Radiating (Meeting AGO Standards)
• Expression Type: Balanced Expression Shoes/Pedals (Meeting AGO Standards)
• Has crescendo
• Combination action: Adjustable Combination Pistons
• Has combination thumb pistons

Notes

2009-01-24 - Identified from factory documents and publications courtesy of Stephen Schnurr. -Database Manager

2009-08-30 - Updated through on-line information from Jeff Scofield. -Database Manager

Stoplist

Stoplist coped from the factory specifications Source: Source not recorded Date not recorded

         Swanton, Ohio
         Trinity Methodist Church

         Möller   Op. 10396  1968   2/8

         The Great and Swell are under separate expression.

         GREAT
 1.  16' Bourdon            85 pipes
 2.   8' Principal          80 pipes
 3.   8' Rohrflöte          from #1
 4.   4' Octave             from #2
 5.   4' Rohrflöte          from #1
 6.   2' Super Octave       from #2 (repeat top 5 notes)
 7.  II  Mixture            122 pipes
 8.      Tremolo
 9.      Chimes             25 tubes, present tubes, new electric action

         SWELL
10.   8' Holzgedeckt        80 pipes
11.   8' Viola da Gamba     73 pipes
12.   8' Dulciana Celeste   49 pipes tc
13.   4' Gedeckt            from #10
14.   4' Viola da Gamba     from #11
15.   2' Flute              from #10 (repeat top 5 notes)
16.  16' Contra Trompette   85 pipes, 1-6 half-length
17.   8' Trompette          from #16
18.   4' Clarion            from #16
19.      Tremolo

         PEDAL
20.  16' Bourdon            from #1
21.   8' Principal          from #2
22.   8' Rohrflöte          from #1
23.   8' Viola da Gamba     from #11
24.   4' Octave             from #2
25.   4' Rohrflöte          from #1
26.  II  Mixture            from #7
27.  16' Contra Trompette   from #16
28.   8' Trompette          from #16
29.   4' Clarion            from #16

[Received on line from Jeff Scofield August 30, 2009.]
