Better Pipe Organ Database

M. P. Möller Opus 10417 (1969)

St. Procopius Abbey Church
5601 College Road
Lisle, IL

Images

1969-03-21 - Church Interior, Chancel, and Pipe Display (Möller Promotional Photo; collection of Jeff Scofield/Database Manager)

1969-06-30 - Sanctuary interior and exposed pipework (Photograph from a 1981 Möller brochure in the collection of James R. Stettner/Database Manager)

2024-06-05 - Console (Daniel Boin/Daniel Boin)

Consoles

Main

Organ type: Traditional Without Cover
Console position: Console in Fixed Position, Right
3 manuals
25 stops
37 registers
4 divisions
Key action Type: Electrical
Stop action Type: Electrical
Stop layout Type: Drawknobs in Vertical Rows on Angled Jambs
Manual compass: 61 notes
Pedal compass: 32 notes
Pedal Type: Concave Radiating (Meeting AGO Standards)
Expression Type: Balanced Expression Shoes/Pedals (Meeting AGO Standards)
Combination action: Remote Pneumatic/Mechanical Capture
Has combination thumb pistons
Has coupler toe pistons
Has tutti thumb pistons
Has tutti toe pistons

Notes

2009-01-24 - Identified from factory documents and publications courtesy of Stephen Schnurr. -Database Manager

2009-08-31 - Updated through online information from Jeff Scofield. -Database Manager

2012-04-11 - Updated through online information from Kristina Powers. -Database Manager

Stoplist

Stoplist copied from the factory specifications Source: Source not recorded Date not recorded

        Lisle, Illinois
        Saint Procopious Abbey

        Möller   Op. 10417   1969   3/35

        GREAT                            POSITIV
    16' Quintade *                    8' Bordun 61
     8' Principal 61                  4' Koppelflöte 61
     8' Rohrflöte 61                  2' Prinzipal 61
     8' Spitzgambe SW             1 1/3' Larigot 61
     4' Octave 61                   III  Zimbel 183
     4' Nachthorn 61                  8' Krummhorn 61
     2' Doublette 61                     Tremolo (enclosed)
III-IV  Fourniture 220
     8' Trompete 73                      PEDAL
       (double trebles)              32' Resultant --
        Tremolo                      16' Principal 32
        Super                        16' Bourdon 32
                                     16' Quintade 12 SW
     *  From SW Gedeckt               8' Octave 12
        and PD Quintade               8' Rohrbourdon 12
                                      8' Gedeckt SW
        SWELL                         4' Choralbass 32
     8' Gedeckt 61                    4' Rohrgedeckt 12
     8' Spitzgambe 61               III  Mixture 96
     8' Spitzgambe Celeste 54 GG     16' Posaune 12 GT
     4' Weitprinzipal 61              8' Trumpet GT
     2' Blockflöte 61                 4' Krummhorn PO
   III  Scharf 183
    16' Fagot 61 (1-18 L/2)
     8' Fagot 12
     4' Clairon 61
        Tremolo
        Sub
        Super

[Received on line from Jeff Scofield August 31, 2009.]
