Daniel Jaeckel Inc. Opus 40 (2000)

St. Mary Episcopal Church
306 S. Prospect Avenue
Park Ridge, IL

Images

2023-10-25 - Keydesk (Photograph by Daniel Boin/Daniel Boin)

2020-11-25 - Organ case, facade and console (Photograph by Emma Schneider/Emma Schneider)

Consoles

Main

Organ type: Traditional Without Cover
Console position: Keydesk Attached, Manuals Set Into Case
2 manuals
21 stops
25 registers
Key action Type: Mechanical (Details Unknown)
Stop action Type: Electrical
Stop layout Type: Drawknobs in Horizontal Rows on Terraced/Stepped Jambs
Manual compass: 61 notes
Pedal compass: 32 notes
Pedal Type: Concave Radiating (Meeting AGO Standards)
Expression Type: Balanced Expression Shoes/Pedals (Meeting AGO Standards)
Combination action: Adjustable Combination Pistons
Has combination thumb pistons
Has combination toe pistons
Has coupler toe pistons
Has tutti toe pistons

Notes

2009-04-06 - Identified through online information from Joshua Whiteneck. -Database Manager

Stoplist

Stoplist from builder's web site Source: Source not recorded Date not recorded

Park Ridge, Illinois
St. Mary's Episcopal Church

Jaeckel Organs   Opus 40   2000
2 manuals, 21 stops, 23 ranks
________________________________________

          GREAT ORGAN
      16' Contra Gambe         49 a
       8' Open Diapason        61 b
       8' Concert Flute        49 c
       8' Salicional *         61 b
       8' Vox Celeste (TC) *   49
       8' Stopped Diapason *   61
       4' Octave               61
       4' Fugara *             61 b
       2' Italian Principal *  61
       8' Tromba *             61
          * enclosed

          SWELL ORGAN
       8' Viola Diapason       57 d
       8' Rohr Flute           61
       8' Melodia              61
       4' Viola Octave         61
       4' Flauto Traverso      61
       3' Nazard               61
       2' Mixture III         183
      16' Fagotto              61
       8' Oboe                 61

          PEDAL ORGAN
      16' Open Diapason        32
      16' Bourdon              32
       8' Open Diapason        GT b
       8' Salicional           GT b
       4' Fugara               GT b
       8' Tromba               GT

       a  1-12 from PD 16' Bourdon
       b  either/or only, not both at
          the same time (unless coupled)
       c  1-12 from GT Open Diapason

          COUPLERS (mechanical)
          Great to Pedal
          Great to Pedal 4'
          Swell to Pedal
          Swell to Great
          Great to Great 4'



[Received from Steven E. Lawson  2015-10-12]
