Schantz Organ Co. Opus 2234 (2004)

Wilshire Baptist Church
4316 Abrams Rd
Dallas, TX

Consoles

Main

Organ type: Traditional With Roll Top
Console position: Movable Console
4 manuals
60 stops
90 registers
7 divisions
Key action Type: Electrical
Stop action Type: Electrical
Stop layout Type: Drawknobs in Vertical Rows on Angled Jambs
Manual compass: 61 notes
Pedal compass: 32 notes
Pedal Type: Concave Radiating (Meeting AGO Standards)
Expression Type: Balanced Expression Shoes/Pedals (Meeting AGO Standards)
Has crescendo
Combination action: Computerized/Digital
Has sequencer
Has combination thumb pistons
Has combination toe pistons
Has coupler toe pistons
Has tutti thumb pistons
Has tutti toe pistons

Notes

2009-05-10 - Identified through on-line information from Stephen Hall. -- Organ is in regular use for services (per church website, accessed 5-07-2009). Technical information from builder's website accessed 5-07-2009. -Database Manager

Stoplist

Stoplist from Schantz factory specifications Source: Source not recorded Date not recorded

Dallas, Texas
WILSHIRE BAPTIST CHURCH

Schantz Organ Company      Opus 2234      79 ranks     2004
______________________________________________________________________

GREAT:                              CHOIR:
   16' Violone 73                      16' Quintaton 61
    8' Open Diapason 61                 8' English Diapason 61
    8' Violone                          8' Erzähler II 110
    8' Bourdon 61                       8' Gedeckt 61
    8' Harmonic Flute 49                4' Principal 61
    4' Octave 61                        4' Koppelflöte 61
    4' Spire Flute 61                   2' Fife 61
2 2/3' Twelfth 61                   1 1/3' Quinte 61
    2' Fifteenth 61                    II  Sesquialtera 122
1 3/5' Seventeenth 61                  IV  Fourniture 244
   IV  Mixture 244                      8' Clarinet 61
  III  Scharf 183                          Tremulant
    8' Trumpet 61
       Tremulant                    SWELL:
    8' Trompette en Chamade 61         16' Stopped Bass 73
    8' Tuba Major [SOLO]                8' Geigen Diapason 61
       Chimes                           8' Salicional 61
       Zimbelstern                      8' Voix Celeste [GG]
                                        8' Chimney Flute
SOLO:                                   4' Principal 61
    8' Flauto Mirabilis 61              4' Nachthorn 61
    8' Violoncello 61               2 2/3' Nasard 61
    8' English Horn 61                  2' Octavin 61
    8' Orchestral Oboe 61           1 3/5' Tierce 61
       Tremulant                       IV  Plein Jeu 244
       Chimes                          16' Bombarde 73
    8' Tuba Major 61                    8' Trumpet
   16' Bombarde en Chamade [TC]         8' Oboe 61
    8' Trompette en Chamade [GT]        4' Clarion 61
                                        8' Vox Humana 61
PEDAL:                                     Tremulant
   32' Double Open Diapason prep        8' Trompette en Chamade [GT]
   32' Untersatz prep
   16' Open Diapason 32             ANTIPHONAL ORGAN:
   16' Violone [GT]                     8' Principal 61
   16' Bourdon 56                       8' Stopped Flute 61
   16' Stopped Bass [SW]                8' Viole 61
   16' Quintaton [CH]                   8' Viole Celeste [TC] 49
    8' Octave 32                        4' Octave 61
    8' Violone [GT]                     4' Spitzflöte 61
    8' Bourdon                          2' Gemshorn 61
    8' Stopped Bass [SW]               IV  Mixture 244
    4' Choral Bass 32                   8' Fagotto 61
    4' Open Flute                          Tremulant
   IV  Mixture 128
   32' Ophicleide prep              ANTIPHONAL PEDAL ORGAN:
   16' Trombone 56                     32' Resultant
   16' Bombarde [SW]                   16' Subbass 12
    8' Tromba                           8' Stopped Bass
    8' Trumpet [GT]                    16' Contra Fagotto 12
    4' Clarion                          8' Fagotto
    4' Schalmei 32
    4' Oboe Clarion [SW]
    8' Trompette en Chamade [GT]
    8' Tuba Major [SOLO]
    4' Tuba Clarion [SOLO]
       Chimes

[Received on line from Chad Boorsma February 03, 2010.]
