St. Joan of Arc Catholic Church
22412 Overlake Drive
St. Clair Shores, MI
Images
2020-03-06 - Builder nameplate (Photograph by Roman Lizak, submitted by Jeff Scofield/Jeff Scofield)
2010-02-28 - Church exterior (Photograph from an archival source: Church Facebook, submitted by Jeff Scofield/Jeff Scofield)
2020-07-31 - Church interior (Photograph from an archival source: Church Facebook, submitted by Jeff Scofield/Jeff Scofield)
2020-03-06 - Console (Photograph by Church Facebook, submitted by Jeff Scofield/Jeff Scofield)
2020-03-06 - Nave interior with rear gallery and organ (Photograph by Roman Lizak/Database Manager)
2020-03-06 - Rear gallery and organ (Photograph by Roman Lizak/Database Manager)
2020-03-06 - Console (Photograph by Roman Lizak/Database Manager)
2020-03-06 - Console: right stopjamb (Photograph by Roman Lizak/Database Manager)
2020-03-06 - Console: left stopjamb (Photograph by Roman Lizak/Database Manager)
Consoles
Main
- Organ type: Traditional With Roll Top
- Console position: Console in Fixed Position, Center
- 3 manuals
- 35 stops
- 39 registers
- 4 divisions
- Key action Type: Electrical
- Stop action Type: Electrical
- Stop layout Type: Drawknobs in Vertical Rows on Angled Jambs
- Manual compass: 61 notes
- Pedal compass: 32 notes
- Pedal Type: Concave Radiating (Meeting AGO Standards)
- Expression Type: Balanced Expression Shoes/Pedals (Meeting AGO Standards)
- Has crescendo
- Combination action: Adjustable Combination Pistons
- Has combination thumb pistons
- Has combination toe pistons
- Has coupler thumb pistons
- Has coupler toe pistons
- Has tutti toe pistons
Notes
2009-11-23 - Identified by Rae Bolton from information furnished by Casavant Frères, courtesy of Simon Couture. -Database Manager
2010-06-25 - Updated through on-line information from Jeff Scofield. -Database Manager
2020-04-09 - Updated through on-line information from James R. Stettner. -- From photos taken in March 2020, it appears that the organ has had a solid state upgrade as there is a MIDI drawknob available in each division now, and an LED control panel is visible to the left of the coupler rail. However no tonal changes or additions are evident. -Database Manager
Stoplist
Stoplist copied from the factory specifications Source: Source not recorded Date not recorded
St. Clair Shores, Michigan
St. Joan of Arc R.C. Church
CASAVANT, Opus 2827, 1965 3/46
_________________________________________________
<u>GREAT</u> <u>SWELL (Expressive)</u>
16 Quintade 61 8 Viola 61
8 Diapason 61 8 Viola Celeste (tc) 49
8 Bourdon 61 8 Rohr Flöte 61
8 Erzähler 61 4 Principal 61
4 Octave 61 4 Flute Traversiere 61
4 Spitz Flöte 61 2 2/3 Nazard 61
2 Super Octave 61 2 Block Flöte 61
IV Mixture 1⅓ 244 IV Scharff 244
8 Trompette 61 8 Trompette 61
MIDI 4 Schalmei 61
Tremulant
MIDI
<u>PEDAL</u> Swell 16
16 Principal 32 Swell 4
16 Subbass 32
16 Quintade (Gt) --
10⅔ Quinte 32 <u>POSITIV (Ruckpositiv)</u>
8 Principal 32 8 Gedeckt 61
8 Subbass 12 4 Koppel Flöte 61
4 Choral Bass 32 2 Flute Conique 61
2 Octave 32 1 1/3 Larigot 61
III Mixture 2 96 1 Sifflöte 61
16 Bombarde 32 II Sesquialtera 2⅔ 122
8 Trompette 12 III Zimbel ⅓ 183
4 Clairon 12 8 Krummhorn 61
MIDI MIDI
<u>COUPLERS</u> <u>FINGER PISTONS</u>
Swell to Pedal 8,4 General 1 - 16
Great to Pedal 8 Swell 1 - 6
Positiv to Pedal 8 Sw to Ped (rev)
Sw to Gt (rev)
Swell to Great 16,8,4 Sw to Pos (rev)
Positiv to Great 16,8,4 Great 1 - 6
Gt to Ped (rev)
Swell to Positiv 16,8,4 Positiv 1 - 6
Pos to Ped (rev)
Pos to Gt (rev)
<u>TOE STUDS</u> Pedal 1 - 6
General 1 - 16 Full (rev)
Pedal 1 - 6 Scope
Sw. to Ped. (rev) Cancel [blank]
Gr. to Ped. (rev)
Pos. to Ped. (rev)
Full (rev) <u>PEDAL MOVEMENTS</u>
Swell Expression (bal.)
Crescendo (bal.)
Courtesy of the Casavant Frères Archives, St. Hyacinthe, Québec, Canada
Verified, corrected, & updated by James R. Stettner, March 7, 2020
