Note: Not extant. Not playable. (in this location)
2013-01-25 - This entry describes an original installation of a new pipe organ. Identified by Grant Chapman, based on personal knowledge of the organ. -- -Database Manager
2013-03-13 - Updated through online information from Jeff Scofield. -Database Manager
2019-02-19 - Updated by Jim Lewis <br> <br>February, 2019: The former Elks Temple is now known as The MacArthur and the large public rooms are used for event and filming rentals. The current owners want the organ out of the building (as of 2/19)and the salvageable pipework has been removed and sold. There is a great amount of damage to the instrument due to workmen stepping on pipework and recent earthquakes. Due to limited access to the chambers, the large pedal stops and wind chests will be reduced in size for removal and disposal. The two consoles (4m & 2m) will probably be retained and put on display. -Database Manager
Record copy from personal files. Source: Source not recorded Date not recorded
Los Angeles, California
Elks Lodge #99
The Robert Morton Organ Company of Van Nuys, California
PEDAL CHAMBER & GREAT UNENCLOSED Left Side
1. Open Diapason 16’
2. Trombone 16’
3. Violone 16’
4. Open Diapason (Great 1st) 8’
5. Gross Flute (Great) 8’
Chime
SOLO CHAMBER Above & behind Pedal Chamber
6. Tuba Mirabilis 8’
7. Stentorphone 8’
8. Philomela 8’
9. Gross Gamba 8’
10. Orchestral Oboe 8’ [English Post Horn 8’]
SWELL CHAMBER Upper Right Side
11. Contra Fagotto 16’
12. Tibia Clausa 16’
13. Bourdon 16’
14. Trumpet 8’
15. Violin Diapason 8’
16. Tibia Mollis 8’ [Empty Chest]
17. Kinura 8’ [English Post Horn 8’ Orchestral Oboe 8’]
18. Vox Humana 8’
19. Violin I 8’
20. Violin II 8’
21. Violin III 8’
22. Violin D’orchestra 8’
23. Violin Celeste 8’
24. Salicional 8’
25. Aeoline 8’
26. Flute Traverso 4’
ECHO & ANTIPHONAL CHAMBER [Also called Memorial Organ]
(Antiphonal) Over Lodge Room Entrance
27. Cornopean 8’
28. Open Diapason 8’
29. Hohl Flute 8’
(Echo)
30. Echo Bourdon 16’
31. Night Horn 8’
32. Flute Celeste TC 8’
33. Viol Sordo 8’
34. Viol Ætheria 8’
35. Vox Humana 8’
36. Fern Flute 4’
37. Violetta 4’
Bird
Chime
GREAT & CHOIR CHAMBER Lower Right Side
38. Pedal Bourdon 16’
(Great Organ)
39. Open Diapason 8’
40. Tuba 8’
41. French Horn 8’
42. Oboe Horn 8’ [Kinura 8’]
43. Gamba 8’
44. Doppel Flute 8’
45. Quintadena 8’
46. Cornet 2 2/3’ [3Rk. Mixture]
(Choir Organ)
47. Dulciana 16’
48. English Diapason 8’
49. Flugel Horn 8’
50. Clarabella 8’
51. Clarinet 8’
52. Gemshorn 8’
53. Viola 8’
54. Unda Maris TC 8’
55. Harmonic Flute 4’
56. Flageolet 2’
(Percussions & Traps)
• Wood Harp
• Glockenspiel (Chrysoglott)
• Xylophone
• Bass Drum (Tap & Roll Actions)
• Snare Drum (Tap & Roll Actions)
• Cymbal
• Crash Cymbal
• Chinese Gong
• Klaxon
• Wind Siren
• Cow Bell
• Telephone Bell
• Birds (2)
• Tom Tom
• Castanets
• Sleigh Bells
• Wood Block
• Tambourine
• Police Siren (On loan from R.T. Stoney)
RECORD COPY WITH CORRECTIONS
Stop Braille Stop Name and Tip Notes
Color Marking Mark
GREAT (Lower Right Chamber)
1. Bn DP Open Diapason 16 DIA Unenclosed at left
2. Bu Gamba TC 16 GAM No. 11
3. Bn DP 1st Open Diapason 8 DIA Unenclosed at left
4. Bn 2nd Open Diapason 8 DIA
5. Re Tuba 8 TU
6. Re French Horn 8 HORN
7. Re Kinura 8 KIN
8. Wh Gross Flute 8 G-FL Unenclosed at left
9. Wh Clarabella 8 CLAR No. 80
10. Wh Doppel Flute 8 D-EL
11. Bu Gamba 8 GAM
12. Bu Violin I 8 V-I No. 52, Swell
13. Bu Violin II 8 V-II No. 53, Swell
14. Bu Violin III 8 V-III No. 54, Swell
15. Pk Quintadena 8 QUIN
16. Pk Dulciana 8 DUL No. 77
17. Re TN Tuba Clarion 4 TN No. 5
18. Bn Octave Diapason 4 DIA No. 4
19. Wh Doppel Flute 4 S-FL No. 10
20. Bn MX Cornet 3 RK MIXT 12-15-17 Dolce
21. Bn DP Twelfth 2 2/3 DIA No. 4
22. Bn DP Fifteenth 2 DIA No. 4
23. Ye HP Harp H Wood
24. Ye GL Glockenspiel G Chrysoglott
25. Ye XY Xylophone X
26. Ye C Chimes C In echo chamber In Pedal
27. Bu FF Strings FF All SW strings 8 & 4
ANTIPHONAL ON GREAT
28. Re CN Cornopean 8 COR
29. Bn Open Diapason 8 DIA
30. Wh Hohl Flute 8 H-FL
Stop Braille Stop Name and Tip Notes
Color Marking Mark
ECHO ON GREAT
31. Wh EB Echo Bourdon 16 BOUR
32. Re HO Night Horn 8 HORN Stopped Flute
33. Wh Flute Celeste TC 8 FL-CL
34. Bu Viol Sordo 8 V-S
35. Bu Viol AEtheria 8 V-E
36. Re Vox Humana 8 VOX
37. Wh FL Fern Flute 4 F-FL
38. Bu Violetta 4 V
39. Ye BD Bird BIRD
GREAT SECOND TOUCH
196. Re Tuba 8 TN No. 5
197. Re French Horn 8 HORN No. 6
198. Wh Gross Flute 8 G—FL No. 8
199. Bu Gamba 8 GAM No. 11
SWELL (Upper right chamber)
40. Re CF Contra Fagotto 16 FAG
41. Wh TB Tibia Clausa 16 TIB
42. Wh Swell Bourdon 16 BOUR
43. Bu Violin TC 16 V-I No. 52
44. Re TR Trumpet 8 TRUM
45. Bn Open Diapason 8 DIA No. 4
46. Bn Violin Diapason 8 V-DIA
47. Wh Tibia Mollis 8 TIB No pipes in chest
48. Wh TB Tibia Clausa 8 TIB No. 41
49. Wh Gedacht 8 BOUR No. 42
50. Re PH English Post Horn 8 POST Orchestral Oboe 8 OB
51. Re Vox Humana 8 VOX
52. Bu Violin I 8 V—I
53. Bu Violin II 8 V—II
54. Bu Violin III 8 V—III
55. Bu Viol d’Orch. 8 VDO
56. Bu Viol Celeste 8 V—CL
Stop Braille Stop Name and Tip Notes
Color Marking Mark
57. Bu Salicional 8 SAL
58. Bu Aeoline 8 AEO
59. Bn DP Octave Diapason 4 DIA No. 4
60. Wh TB Tibia Clausa 4 TIB No. 41
61. Wh Bourdon Flute 4 BOUR No. 42
62. Wh Flute Traverso 4 FL-TR
63. Re Vox Humana 4 VOX No. 51
64. Bu Violina 4 V-I No. 52
65. Bu Salicet 4 SAL No. 57
66. Wh NZ Tibia Nazard 2 2/3 TIB No. 41
67. Wh TB Tibia Piccolo 2 TIB No. 41
68. Ye HP Harp H No. 23, Great
69. Ye GL Glockenspiel G No. 24, Great
70. Ye XY Xylophone X No. 25, Great
71. Ye C Chimes C No. 26, Echo
72. Ye BD Bird BIRD Great
73. Bu P Strings P Nos. 55-58
74. Bu MF Strings MF Nos. 52—54
75. Bu FF Strings FF Nos. 52-58-64-65
SWELL SECOND TOUCH
91. Re Contra Fagotto 16 FAG No. 40
192. Re Trumpet TC 16 TRUM No, 44
193. Wh Tibia Clausa 16 TIB No, 41
194. Wh Swell Bourdon 8 BOUR No. 42
195. Wh Flute Traverse 4 FL-TR No. 62
CHOIR (Lower right chamber)
76. Bu VI Violin TO 16 V-I No. 52, Swell
77. Pk Double Dulciana 16 DUL
78. Bn OP English Diapason 8 E-DIA
79. Re Flugel Horn 8 HORN
80. Wh Clarabella 8 CLAR
81. Re Clarinet 8 CL
82. Pk Gemshorn 8 GEM
Stop Braille Stop Name and Tip Notes
Color Marking Mark
83. Bu Viola 8 V
84. Bu Violin I 8 V-I No. 52, Swell
85. Bu Violin II 8 V-II No. 53, Swell
86. Bu Violin III 8 V-III No. 54, Swell
87. Pk Dulciana 8 DUL No. 77
88. Pk Unda Maris TC 8 U-MAR Stopped Wood Flute
89. Ye HF Harm Flute 4 H-FL
90. Bu Violina 4 V-I No. 52, Swell
91. Pk Dulcet 4 DUL No. 77
92. Wh FL Flageolet 2 FL
93. Pk Dulcissimo 2 DUL No. 77
94. Ye HP Harp H No. 23
95. Ye ST Snare Drum Tap S-DR
96. Ye SR Snare Drum Roll S-DR
97. Ye TT Tom Tom TOM
98. Ye CS Castanets CAS
99. Ye SB Sleigh Bells SB
100. Ye BL Wood Drum W-DR Chinese wood block
101. Ye TM Tambourine TAM
102. Ye FF Strings FF All Swell Strings 8&4.
CHOIR SECOND TOUCH
200. Bn English Diapason 8 E-DIA No. 78
201. Re Flugel Horn 8 HORN No. 79
202. Wh Clarabella 8 CLAR No. 80
203. Re Clarinet 8 CL No. 81
SOLO (Left Chamber-enclosed)
103. Re TU Tuba Mirabilis 8 TU-M
104. Bn Stentorphone 8 STEN
105. Wh Philomela 8 PHIL
106. Bu Gross Gamba 8 GAM
107. Re PH Orchestral Oboe 8 OB English Post Horn 8 HORN
108. Re TU Tuba Clarion 4 TU -M No. 103
109. Bu Gambette 4 GAM No. 106
110. Ye C Chimes No. 26 Echo
Stop Braille Stop Name and Tip Notes
Color Marking Mark
ANTIPHONAL ON SOLO (Echo Chamber)
111. Re CN Cornopean 8 COR No. 28
112. Bn Open Diapason 8 DIA No. 29
113. Wh Hohl Flute 8 H-FL No. 30
ECHO ON SOLO
114. Wh BD Echo Bourdon 16 BOUR No. 31
115. Re HO Night Horn 8 HORN No. 32
116. Wh Flute Celeste TC 8 FL-CL No. 33
117. Bu Viol Sordo 8 V-S No. 34
118. Bu Viol Ætheria 8 V-B No. 35
119. Re Vox Humana 8 VOX No. 36
120. Wh FL Fern Flute 4 F-FL No. 37
121. Bu Violetta 4 V No. 38
122. Ye BD Bird BIRD No. 39
PEDAL (Unenclosed at left)
123. Bn DP Resultant Bas 32 DIA No. 1
124. Bn DP Dbl Opn Diapason 16 DIA No. 1
125. Re Trombone 16 TR
126. Wh Pedal Bourdon 16 FL Great Chamber
127. Wh Tibia Clausa 16 TIB No. 41, Swell
128. Wh Echo Bourdon 16 BOUR No. 31, Echo
129. Re Contra Fagotto 16 FAG No. 41, Swell
130. Bu Violone 16 V
131. Pk Dulciana 16 DUL No. 77, Choir
132. Re TU Tuba 8 TU No. 5, Great
133. Bn Diapason 8 DIA No. 4, Great
134. Re PH English Post Horn 8 POST Orch Oboe 8 OB No. 50, Swell
135. Wh Pedal Flute 8 FL No. 126
136. Wh Doppel Flute 8 D-FL No. 10, Great
137. Wh Echo Flute 8 BOUR No. 31, Echo
138. Bu Cello 8 V No. 130
139. Pk Dulciana 8 DUL No. 77, Choir
Stop Braille Stop Name and Tip Notes
Color Marking Mark
140. Re TU Tuba Clarion 4 TU No. 5, Great
141. Wh Pedal Flute 4 FL No. 126
142. Wh Dulcet 4 DUL No. 77, Choir
143. Bn Cornet 3 RK MIXT No. 20, Great
144. Blank
145. Blank
PEDAL TRAPS (In Choir Chamber)
146. Ye BD Bass Drum B-DR
147. Ye TM Tympani TYM Bass Drum Roll
148. Ye SD Snare Drum S-DR No. 96, Choir
149. Ye CY Bass Drum Cymbal B-DR
PEDAL COUPLERS
150. Bk PD Pedal 8 Octave coupler
151. Bk GR Great 8
152. Bk GR Great 4
153. Bk SW Swell 8
154. Bk SW Swell 4
155. Bk CH Choir 8
156. Bk SO Solo 8
SWELL COUPLERS
157. Bk SW Swell 16
158. Bk SW Swell 4
159. Bk CH Choir 16
160. Bk CH Choir 8
161. Bk CH Choir 4
162. Bk SO Solo 16
163. Bk SO Solo 8
164. Bk SO Solo 4
Stop Braille Stop Name and Tip Notes
Color Marking Mark
GREAT COUPLERS
165. Bk GR Great 16
166. Bk GR Great 4
167. Bk SW Swell 16
168. Bk SW Swell 8
169. Bk SW Swell 4
170. Bk CH Choir 16
171. Bk CH Choir 8
172. Bk CH Choir 4
173. Bk SO Solo 16
174. Bk SO Solo 8
175. Bk SO Solo 4
CHOIR COUPLERS
176. Bk CH Choir 16
177. Bk CH Choir 4
178. Bk SW Swell 16
179. Bk SW Swell 8
180. Bk SW Swell 4
SOLO COUPLERS
181. Bk SO Solo 16
182. Bk SO Solo 4
TRAPS AND MECHANICALS, TOE-OPERATED
281. Sforzando Toe Stud, Right Toe Board
282. Great to Pedal, Reversible 8’ Toe Button, Right Too Board
283. Swell to Pedal, Reversible 8’ Toe Button, Right Too Board
284. Crash Cymbal Toe Stud, Le Toe Board
285. Chinese Gong Toe Stud, Left Toe Board
TREMOLOS (Far right tabs on top row)
183. Bn SW Swell
184. Bn GR Great and Great unenclosed in pedal chamber.
185. Bn CH Choir
186. Bn SO Solo
187. Bn AN Antiphonal
188. Bn EC Echo
189. Bn SV/TB Swell Vox Humana and Tibia Clausa
190. Bn EV Echo Vox Humana
TRAPS (Buttons over Solo Manual)
204. KL Klaxon
205. SI Siren
206. CB Cow Bell
207. TB Telephone Bell
208. BD Bird.
UNISONS (Tilt tablets on right key cheeks)
209. Choir Manual I
210. Great Manual II
211. Swell Manual III
212. Solo Manual IV
MECHANICALS
213. Chimes FF. Button over Solo (Right)
214. Chimes PP. Button over Solo (Right)
215. Chimes Damper Release Button over Solo (Right)
216. Chimes Damper Button over Solo (Right)
217. Tremolos OFF R Button over Solo (Right)
218. 16’ and 4’ Couplers Off R Button over Solo (Right)
219. Pedal Traps on 2nd Touch Tilt Tab over Solo (Left) Non-Op
220. General (Combinations) Tilt Tab below Choir Left cheek.
221. Pedal to Choir (Combons) Tilt Tab Choir left key cheek.
222. Pedal to Great (Combons) Tilt Tab Great left key cheek.
223. Pedal to Swell (Combons) Tilt Tab Swell left key cheek.
224. Pedal to Solo (Combons) Tilt Tab Solo left key cheek.
225. 5 Pedal Combination Pistons Below Choir Manual—Left Group
230. 10 Choir Combination Pistons Below Choir Manual-Center Group
240. 10 Great Combination Pistons Below Great Manual
250. 10 Swell Combination Pistons Below Swell Manual
260. 10 Solo Combination Pistons Below Solo Manual
270. General Cancel 0 Below Choir Manual-Right End
271. Echo to Memorial (Shutter Coupler) Toggle Switch, Left Jamb
272. Echo to Lodge (Shutter Coupler) Toggle Switch, Left Jamb
273. Master Expression (Shutter Coupler)Toggle Switch, Left Jamb
274. Echo Expression Pedal Balanced Pedal, 1st (Left)
275. Great/Choir Expression Pedal Balanced Pedal, 2nd
276. Swell Expression Pedal Balanced Pedal, 3rd
277. Solo/Master Expression Pedal Balanced Pedal, 4th
278. Crescendo (Register) Balanced Pedal, 5th (Right)
279. Chime Piston C (Lo-C) Left of #219
280. Reversible Toe Stud, Left Toe Board
INDICATORS
286. Main D.C. Power Indicator Lamp Left of #150
287. Memorial D.C. Power Indicator Lamp Left of #150
288. Sforzando Indicator Lamp Right of #182
289. Crescendo Digital Indicator 0 thru 8 Right of #182
290. Audible Sforzando/Crescendo warning
(Operates when GC is depressed and Sfz. or Cres. has been left on.)
Special thanks to R. P. Bass & R. T. Stoney
[Received from Grant Chapman 2013-01-29.]Regrettably, it is not possible to display the information about the sponsor of this pipeorgandatabase entry or if there is a sponsor. Please see About Sponsors on Pipe Organ Database.
