Austin Organs, Inc. (2002)

Images

2019-09-20 - Console (Photograph by Joe Routon/Joe Routon)

2019-09-20 - Console on Irvine Auditorium stage (Photograph by Joe Routon/Joe Routon)

2015-08-29 - Console (Photograph by Joseph Routon, submitted by Jeff Scofield/Jeff Scofield)

2015-08-29 - Auditorium interior (Photograph by Joseph Routon, submitted by Jeff Scofield/Jeff Scofield)

2015-06-23 - Auditorium interior (Photograph by Martin Doering via https://die-orgelseite.de, submitted by Jeff Scofield/Jeff Scofield)

2003 - Auditorium interior to rear (Photograph by University of Pennsylvania, submitted by Jeff Scofield/Jeff Scofield)

2015-06-23 - Harp (Photograph by Martin Doering via https://die-orgelseite.de, submitted by Jeff Scofield/Jeff Scofield)

2015-06-23 - Austin Universal Windchest: Swell/Great airbox, view of Swell Tremolo section (Photograph by Martin Doering via https://die-orgelseite.de, submitted by Jeff Scofield/Jeff Scofield)

2015-06-23 - Stage and console from upper left of room (Photograph from an archival source: Martin Doering via https://die-orgelseite.de, submitted by Jeff Scofield/Jeff Scofield)

2015-06-23 - Console center close-up (Photograph by Martin Doering via https://die-orgelseite.de, submitted by Jeff Scofield/Jeff Scofield)

2015-06-23 - Console (Photograph by Martin Doering via https://die-orgelseite.de, submitted by Jeff Scofield/Jeff Scofield)

2015-06-23 - Auditorium interior (Photograph by Martin Doering via https://die-orgelseite.de, submitted by Jeff Scofield/Jeff Scofield)

2014-08-21 - Irvine Auditorium showing the facade pipes on Proscenium Pedal chambers. Balance of organ is located behind the stenciled scrim on upper left/right. (Photograph by Paul R Marchesano/Paul R. Marchesano)

2011-02-17 - Console center (Photograph by Stephen Schnurr/Database Manager)

2011-02-12 - Knee panel and swell shoes (Photograph by Stephen Schnurr/Database Manager)

Unknown - Auditorium, pipe facades and console (Photograph by Stephen Schnurr/Database Manager)

2015-08-25 - Console (Photograph by Len Levasseur/Database Manager)

2015-08-25 - Auditorium Interior (Photograph by Len Levasseur/Database Manager)

2015-08-25 - Stage and Console (Photograph by Len Levasseur/Database Manager)

2011-02-21 - String Division Drawknobs (Photograph by Thomas George/Database Manager)

2011-02-21 - Solo and Great Drawknobs (Photograph by Thomas George/Database Manager)

2011-02-21 - Swell and Pedal Drawknobs (Photograph by Thomas George/Database Manager)

2011-02-21 - Console Detail - Touch Screen (Photograph by Thomas George/Database Manager)

Consoles

Main

Notes

2014-05-31 - In 1997 the audtorium was closed for an extensive renovation; the organ was removed by Austin (leaving airboxes and 11 notes of the 32' Open Diapason and 12 notes of the 32' Violone) and re-actioned; it was reinstalled in 2002 with a new console; the consultant for the organ restoration was William F. Czelusniak. A solid state relay and combination system was installed. -Database Manager

Stoplist

Philadelphia, PA Irvine Auditorium Austin Organ Company Opus 1416 Built for the Sesqui-Centennial Exposition 1926 The specifications were drawn by a committee of Philadelphia organists composed of Henry S. Fry, Dr. John McE. Ward, Rollo F. Maitland, Frederick Maxon and S. Wesley Sears. Their idea being it to have it distinctly an "Organists Organ." GREAT ORGAN *Bourdon 16' 73 Pipes Violone Dolce 16' 61 Pipes First Open Diapason 8' 61 Pipes Second Open Diapason 8' 61 Pipes *Third Open Diapason 8' 61 Pipes *Fourth Open Diapason 8' 61 Pipes *Fifth Open Diapason 8' 61 Pipes Gamba 8' *Violoncello 8' 61 Pipes *Gemshorn 8' 61 Pipes *Flauto Major 8' 61 Pipes *Doppel Flote 8' 61 Notes *Bourdon 8' 61 Pipes *Harmonic Flute 8' 61 Pipes *Clarabella 8' 61 Pipes *Quint 5 1/3' 61 Pipes *Octave 4' 61 Pipes Principal 4' 61 Pipes *Hohl Flote 4' 61 Pipes *Harmonic Flute 4' 61 Pipes Octave Quint 2 2/3' 61 Pipes Super Octave 2' 61 Pipes Mixture, 3 and 4 ranks, 232 Pipes *Mixture, 5 ranks 305 Pipes *Double Trumpet 16' 61 Pipes *Trumpet 8' 61 Pipes *French Trumpet 8' 61 Pipes Tuba (from solo,) 8' 61 Notes Clarion 4' 61 Notes French Horn 8' 61 Notes Chimes (Cathedral) G to G (from solo) 25 Notes *Harp (Celesta) 8' 61 Bars and Resonators *Harp (from 8') 4' 61 Notes Tremolo. *Enclosed in Great swell-box SWELL ORGAN Gemshorn 16' 73 Pipes Bourdon 16' 73 Pipes Open Diapason 8' 73 Pipes Diapason Phonon 8' 73 Pipes Geigen Principal, 8' 73 Pipes Horn Diapason 8' 73 Pipes Viole d'Gamba 8' 73 Pipes Salicional 8' 73 Pipes Voix Celeste 8' 73 Pipes Viole D'Orchestre, 8' 73 Pipes Viole Celeste (3 Ranks) 8' 219 Pipes Rohr Flote 8' 73 Pipes Melodia 8' 73 Pipes Flauto Dolce 8' 73 Pipes Unda Maris 8' 61 Pipes Principal 4' 73 Pipes Traverse Flute 4' 73 Pipes Flute d'Amour 4' 73 Pipes Violina 4' 73 Pipes Flautina 2' 73 Pipes Mixture (4 ranks) 244 Pipes *Mixture (5 ranks) 305 Pipes Contra Fagotto 16' 73 Pipes French Trumpet 8' 73 Pipes Corno d'Amore 8' 73 Pipes Oboe 8' 73 Pipes Clarion 4' 61 Pipes Vox Humana (1 rank,) 16' Vox Humana (2 ranks,) 8'; Vox Humana (1 rank,) 4' 146 Pipes Tremolo *Stop Marked (*) is a selective mixture consisting of Twelfth, Fifteenth, Seventeenth, Twenty-First, and Twenty-second. Each Rank has its corresponding stop-key, so that each rank may be drawn separately. CHOIR ORGAN Contra Gamba 16' 73 Pipes Double Dulciana 16' 109 Pipes Dulciana (from 16') 8' 61 Notes Dolce (from 16') 4' 61 Notes Dulcet (from 16') 2' 61 Notes Dulcinet (from 16') 61 Notes Open Diapason 8' 73 Pipes Geigen Principal 8' 73 Pipes Concert Flute 8' 73 Pipes Flute Celeste 8' 61 Pipes Stopped Diapason (Large Scale) 8' 73 Pipes Chimney Flute 8' 73 Pipes Quintadena 8' 73 Pipes Viole d'Orchestre 8' 73 Pipes Viole Celeste 8' 73 Pipes Principal 4' 73 Pipes Gemshorn 8' 73 Pipes Gemshorn Celeste 8' 73 Pipes Flute d'Amour 4' 61 Pipes **Mixture (3 ranks) 183 Pipes Baryton 16' 73 Pipes Trombone 16' 73 Pipes Tromba 8' 61 Pipes Tromba Clarion 4' 73 Pipes Bass Clarinet 16' 73 Pipes Orchestral Horn 8' 73 Pipes Clarinet 8' 73 Pipes Cor Anglais 16' 85 Pipes Cor Anglais 8' 73 Notes Vox Humana (Small) 8' 61 Pipes Orchestral Oboe 8' 61 Pipes Harp (From Great) 8' 61 Notes Harp (From Great) 4' 61 Notes Chimes (From Solo) 25 Notes Tremolo **Selective mixture consisting of Twelfth, Fifteenth, and Seventeenth. Each rank has its corresponding stop-key, so that each rank may be drawn separately. TROMBONE CHORUS (Separate Chamber, Enclosed) Five sets of pipes of 16', 8', 8', 4', & 4' pitch. 305 Pipes One 16' Set Two 8' Sets Two 4' Sets Big Scales, high pressure. SOLO ORGAN Flauto Major 8' 73 Pipes Grand Diapason Phonon (largest scale,) 8' 73 Pipes Gross Gamba 8' 73 Pipes Gamba Celeste 8' 73 Pipes Gedeckt 8' 73 Pipes Flute Ouverte 4' 73 Pipes Concert Piccolo 2' 61 Pipes Tuba Profunda 16' 73 Pipes Harmonic Tuba 8' 73 Pipes Tuba Clarion 4' 73 Pipes French Horn (from Great) 8' 73 Notes Hunting Horn 8' 73 Pipes French Bugle 8' 73 Pipes Bell Clarinet 8' 73 Pipes Orchestral Oboe (from Choir) 8' 73 Notes **Tuba Magna (Open Chest,) High Pressure 8' 73 Pipes Chimes (Cathedral,) 25 Tubes Harp (from Great) 8' 61 Notes Harp (from Great) 4' 61 Notes Clarinet (from Choir) 8' 61 Notes Concert Flute (from Choir) 8' 61 Notes Flute d' Amour (from Choir) 8' 61 Notes Cor Anglais (from Choir) 8' 61 Notes Tremolo. **Extended 73 pipes from 16' in order that it may be available as a 16' stop on the Pedal. STRING ORGAN Floating (at will) on all manuals, with appropriate mechanism for control. Enclosed in its own expression chamber and arranged so that it is controlled from its own expression pedal, as well as from the swell pedal representing the manual in which it is drawn. The expression box constructed to give a wide range of expression. Consists of: 3 ranks 16', Pedal Organ. 20 ranks 8' 3 ranks 4' 3 ranks mutation pitch, 12th, 15th & 17th. The stop keys control same in groups as follows: 5 Ranks 8' 5 Ranks 8' 3 Ranks 8' 3 Ranks 8' 2 Ranks 8' 2 Ranks 8' 3 Ranks 4' 3 Ranks Mutation Three ranks (extended) 16' to operate from Pedal organ. Three ranks (from manual) 8' to operate from Pedal organ. One stop key controlling entire String organ. Tremolo PEDAL ORGAN Resultant 64' 32 Notes Double Open Diapason 32' 68 Pipes Contra Violone 32' 44 Pipes Conrta Bourdon 32' 63 Pipes Diaphone 16' 32 Pipes Open Diapason 16' 44 Pipes Open Diapason (from 32') 16' 21 Notes Metal Open Diapason 16' 44 Pipes Gamba 16' (from Choir) 32 Notes Violone 16' (from 32') 32 Notes Dulciana 16' (from Choir) 32 Notes Dulciana 8' (from Choir) 32 Notes First Bourdon 16' 32 Pipes Second Bourdon 16' (from 32') 32 Notes Lieblich Gedeckt 16' (from Swell) 32 Notes Gross Quint 10 2/3' (from 32') 32 Notes Octave 8' (from 16' wood-open) 32 Notes Principal 8' (from Metal 16') 32 Notes Gross Flote 8' (from 32' open) 32 Notes Flauto Dolce 8' (from Swell Bourdon) 32 Notes Violoncello Celeste 8' (2 ranks from solo) 32 Notes Twelfth 5 1/3' (from 32') 32 Notes Octave Flute 4' (from 32' Open) 32 Notes Mixture 5 Ranks 160 Pipes Contra Bombarde 32' (enclosed in Solo,) 44 Pipes Bombarde 16' (enclosed in Solo,) 32 Notes Trombone 16' 56 Pipes Tromba 8' (from 16') 32 Notes Clarion 4' (from 16') 32 Notes Tuba Profunda 16' (from Tuba Magna) 32 Notes Harmonic Tuba 8' (from Tuba Magna) 32 Notes Tuba Clarion 4' (from Tuba Magna) 32 Notes Bass Clarinet 16' (from Choir) 32 Notes Contra Fagotto 16' (from Swell) 32 Notes String Celeste 16' (3 Ranks extended String Organ) 32 Notes String Celeste 8' (from manual 3 ranks) 32 Notes Trombone 16' (from Chorus Organ) 32 Notes Xylophone 4' (from Solo Organ) 37 Notes Carillons 4' (from Solo Organ) 37 Notes Glockenspiel 4' (Single Stroke, from Solo Organ) 37 Notes Glockenspiel 4' (Repeating, from Solo Organ) 37 Notes Marimba Harp 8' (Single Stroke, from Great Organ) 49 Notes Marimba Harp 8' (Repeating, from Solo Organ) 49 Notes [Received from Thomas A. George 2014-10-01.]
