St. Katharine of Siena Roman Catholic Church
104 S. Aberdeen Avenue
Wayne, PA
Images
2022 - Detail of the chancel console (Photograph from an archival source: Ruffatti website, submitted by Paul R. Marchesano/Paul R. Marchesano)
2022 - The Positiv division (Photograph from an archival source: Ruffatti website, submitted by Paul R. Marchesano/Paul R. Marchesano)
2022 - The main portion of the instrument, over the rear balcony (Photograph from an archival source: Ruffatti website, submitted by Paul R. Marchesano/Paul R. Marchesano)
2022-07-05 - Positiv principals (Photograph by Monty Bennett/Monty Bennett)
2022-07-05 - Positiv principals (Photograph by Monty Bennett/Monty Bennett)
2022-07-05 - Positive Flutes (Photograph by Monty Bennett/Monty Bennett)
2022-07-05 - Gallery cases containing Great, Swell, and Pedal divisions (Photograph by Monty Bennett/Monty Bennett)
2022-07-05 - Couplers and nameplate (Photograph by Monty Bennett/Monty Bennett)
2022-07-05 - Console (Photograph by Monty Bennett/Monty Bennett)
2022-07-05 - Left Stop jamb (Photograph by Monty Bennett/Monty Bennett)
2022-07-05 - Right stop jamb (Photograph by Monty Bennett/Monty Bennett)
2018 - Artist's rendering of the new pipe organ (Photograph from an archival source: Ruffatti Pipe Organs, submitted by Paul R. Marchesano/Paul R. Marchesano)
Consoles
Main
- 3 manuals
- 29 stops
- 42 registers
- Key action Type: Electrical
- Stop action Type: Electrical
- Manual compass: 61 notes
- Pedal compass: 32 notes
Notes
2018-06-26 - Two matching consoles on movable platforms - one on main floor, the other in the choir gallery. -Database Manager
2020-11-19 - Organ contracted in 2018 with planned installation summer of 2020. Due to the COVID-19 pandemic, installation has been delayed. The organ is complete in the factory awaiting transportation and installation. It is expected that it will be installed in Summer 2022. -Paul R. Marchesano
Stoplist
Typed stoplist Source: from Cunningham Piano Company Date not recorded
Wayne, Pennsylvania
St. Katharine of Siena Roman Catholic Church
Fratelli Ruffatti 2018 3 manuals, 29 stops, 37 ranks
____________________________________________________________________________
Two matching drawknob consoles on movable platforms
GREAT ORGAN SWELL ORGAN
16' Lieblich Gedeckt 73 8' Diapason 61
8' Principal 61 8' Bourdon 61
8' Rohrflöte (fr. LGed) -- 8' Viola da Gamba 61
4' Octave 61 8' Viola Celeste (TC) 49
4' Flauto Traverso 61 4' Principal 61
2' Super Octave 61 4' Flauto Veneziano 61
1 1/3' Mixture IV 244 2 2/3' Nasard 61
8' Trompette 85 2' Blockflöte 61
4' Clairon (fr. Trpt) -- 1 3/5' Tierce 61
Great 16' 2' Plein Jeu IV 244
Unison Off 8' Hautbois 61
Great 4' Tremulant
Swell 16'
POSITIV ORGAN (Antiphonal) Unison Off
16' Gedeckt 73 Swell 4'
8' Geigen Principal 61
8' Gedeckt (fr. 16') -- PEDAL ORGAN
4' Octave 61 32' Resultant --
4' Koppelflöte 61 16' Principal 44
2 2/3' Nazard 61 16' Subbass 56
2' Super Octave 61 16' Lieblich Gedeckt (Gt) --
2' Piccolo 61 16' Kleine Gedeckt (Pos) --
1 3/5' Terz 61 8' Prestant (fr. Princ) --
1' Cymbale III 183 8' Bourdon (fr. Subbass) --
Tremulant 8' Rohrflöte (Gt) --
Positiv 16' 4' Nachthorn (fr. Sub) --
Unison Off 16' Trompette (Gt) --
Positiv 4' 8' Trompette (Gt) --
4' Trompette (Gt) --
[Received from Steven E. Lawson 2018-07-02]
