St. John's Shaughnessy Anglican Church: Nave/Gallery
1490 Nanton Avenue
Vancouver, BC, CA
Images
2020-04-05 - Main Console with Altar rainbow effect (Photograph by Michael Dirk/Michael Dirk)
2020-02-18 - Pedal 16s/32s (Photograph by Michael Dirk/Michael Dirk)
2020-02-18 - Positive division (Photograph by Michael Dirk/Michael Dirk)
2020-02-18 - Swell 2 division (Photograph by Michael Dirk/Michael Dirk)
2020-02-18 - Swell 1 division (Photograph by Michael Dirk/Michael Dirk)
2020-02-18 - Main chamber: Great division plus Pedal Subbass and Octave, Sw2 shades (Photograph by Michael Dirk/Michael Dirk)
2020-02-03 - Gallery console (Photograph by Michael Dirk/Michael Dirk)
2017-04-19 - Gallery from below (Photograph by Michael Dirk/Michael Dirk)
2017-04-19 - Main Chamber (Photograph by Michael Dirk/Michael Dirk)
1992 - Main chamber view from scaffolding (Photograph by SJS/VST/DNW Archives, submitted by Michael Dirk/Michael Dirk)
1968 - Hallman SJS Brochure (Photograph by Hallman/NPOLAC/BillVineer /Michael Dirk)
Summer 1968 - Installed organ at SJS (Photograph from an archival source: Hallman/NPOLAC/BillVineer, submitted by Michael Dirk/Michael Dirk)
1968 - Hallman Shop Pics (Photograph from an archival source: Hallman/NPOLAC/BillVineer, submitted by Michael Dirk/Michael Dirk)
June 1968 - Finished SJS organ complete in the Hallman shop prior to shipping (Photograph from an archival source: Hallman/NPOLAC/BillVineer, submitted by Michael Dirk/Michael Dirk)
2020-10-10 - Main Console (Photograph by Derek Simpkins, submitted by Michael Dirk/Michael Dirk)
Consoles
Main
- Organ type: Traditional With Roll Top
- Console position: Movable Console
- 4 manuals
- 71 stops
- 99 registers
- 7 divisions
- Key action Type: Electrical
- Stop action Type: Electrical
- Stop layout Type: Drawknobs
- Manual compass: 61 notes
- Pedal compass: 32 notes
- Pedal Type: Concave Radiating (Meeting AGO Standards)
- Expression Type: Balanced Expression Shoes/Pedals (Meeting AGO Standards)
- Has crescendo
- Combination action: Computerized/Digital
- Solid State MultiSystem II
- Has sequencer
- Has combination thumb pistons
- Has combination toe pistons
- Has tutti thumb pistons
- Has tutti toe pistons
Gallery
- Organ type: Traditional With Roll Top
- Console position: Movable Console
- 1 manuals
- 9 stops
- 13 registers
- 2 divisions
- Key action Type: Electrical
- Stop action Type: Electrical
- Stop layout Type: Tilting/Rocking Tablets Above Top Manual
- Manual compass: 61 notes
- Pedal compass: 32 notes
- Pedal Type: Concave Radiating (Meeting AGO Standards)
- Expression Type: No Enclosed Divisions
- Combination action: Computerized/Digital
- Solid State MultiSystemII
- Has combination thumb pistons
Notes
2019-03-20 - This entry describes an original installation of a new pipe organ.
<br>Identified by Ian Mason, listing this web site as a source of information: https://www.facebook.com/photo.php?fbid=10100868291877941&set=pcb.10100868292302091&type=3&theater.<br> -Database Manager
2022-11-20 - 56 note Stinkens Oboe rank added to Sw2 August 2022 -Michael Dirk
