Assumption University (College): Chapel of the Holy Spirit
500 Salisbury St
Worcester, MA
Images
2021-09-10 - Blower room (Photograph by John Roper/John Roper)
2021-09-09 - Positiv division (Photograph by John Roper/John Roper)
2021-09-09 - Right great/pedal tower upper (Photograph by John Roper/John Roper)
2021-09-09 - Right great/pedal tower upper (Photograph by John Roper/John Roper)
2021-09-09 - Right great/pedal tower floor (Photograph by John Roper/John Roper)
2021-09-09 - Right great/pedal tower floor (Photograph by John Roper/John Roper)
2021-09-09 - Great chamber (Photograph by John Roper/John Roper)
2021-09-09 - Swell mixture (Photograph by John Roper/John Roper)
2021-09-09 - Swell chamber right (Photograph by John Roper/John Roper)
2021-09-09 - Swell chamber left (Photograph by John Roper/John Roper)
2021-09-09 - Left pedal/great tower upper (Photograph by John Roper/John Roper)
2021-09-09 - Left pedal/great tower floor (Photograph by John Roper/John Roper)
2021-09-09 - Left pedal/great tower upper (Photograph by John Roper/John Roper)
2021-09-09 - Blower room (Photograph by John Roper/John Roper)
2021-09-09 - Console (Photograph by John Roper/John Roper)
2021-09-09 - Room (Photograph by John Roper/John Roper)
2020-08-31 - Great pipework (Photograph by John Roper/John Roper)
2020-08-31 - Right pedal tower pipework (Photograph by John Roper/John Roper)
2020-08-31 - Swell mixture pipework (Photograph by John Roper/John Roper)
2020-08-31 - Swell pipework (Photograph by John Roper/John Roper)
2020-08-31 - Blower chamber and relay located behind the instrument. (Photograph by John Roper/John Roper)
2020-08-31 - Room (Photograph by John Roper/John Roper)
2020-08-31 - Console (Photograph by John Roper/John Roper)
2017-09-04 - Chapel interior (Photograph by Stephen St. Denis/Stephen St. Denis)
2018-05-31 - Chapel exterior (Photograph by Stephen St. Denis/Stephen St. Denis)
2020-01-14 - Left stopjamb (Photograph by John Roper/John Roper)
2020-01-14 - Right stopjamb (Photograph by John Roper/John Roper)
2020-01-14 - Manuals (Photograph by John Roper/John Roper)
2020-01-14 - Dedication nameplate (Photograph by John Roper/John Roper)
2020-01-14 - Builder's nameplate (Photograph by John Roper/John Roper)
2020-08-31 - Pedalboard, swell pedal, and toe pistons (Photograph by John Roper/John Roper)
2020-01-14 - Organ facade great and positiv (Photograph by John Roper/John Roper)
Consoles
Main
- Organ type: Traditional With Roll Top
- Console position: Movable Console
- 3 manuals
- 67 registers
- 4 divisions
- Key action Type: Electrical
- Stop action Type: Electrical
- Stop layout Type: Drawknobs in Vertical Rows on Angled Jambs
- Manual compass: 61 notes
- Pedal compass: 32 notes
- Pedal Type: Concave Radiating (Not Meeting AGO Standards)
- Expression Type: Balanced Expression Shoes/Pedals (Meeting AGO Standards)
- Combination action: Computerized/Digital
- A. J. & L. Taylor TMS 9000
- Has combination thumb pistons
- Has combination toe pistons
- Has tutti thumb pistons
- Has tutti toe pistons
Notes
2021-10-29 - According to the builder's website, the windchests were new for this installation, the original Wicks Direct-Electric action replaced with "electro-mechanical" except for some larger pipes using electro-pneumatic action. -Stephen Hall
Stoplist
Taken from console and builder's website Source: Taken from Console
Stephen J. Russell (& Co.) (Opus 18, 1995)
Assumption College
Great:
16’ Pommer 61
8’ Principal 61
8' Rohrflote 61
8' Flute Harmonique 61
8' Salicional 61
4' Octave 61
4' Nachthorn 61
2' Super Octave 61
IV Mixture 244
III-IV Scharf 232
16' Bombarde 61
8' Trompete 61
8' State Trumpet 61
Swell to Great 16'
Swell to Great 8'
Swell to Great 4'
Positiv to Great 16'
Positiv to Great 8'
Swell:
16' Lieblich Gedeckt (TC) from Gedeckt 8'
8' Geigen Principal from Principal 4', 1-12=Gedeckt + Viole
8' Gedeckt 61
8' Viole 61
8' Voix Celeste (TC) 49
8' Spitzflote 61
8' Spitzflote Celeste (TC) 49
4' Principal 61
4' Koppelflote 61
2 2/3' Nazard 61
2' Flachflote 61
1 3/5' Tierce 61
V Plein Jeu 305
16' Contre Hautbois 12
8' Hautbois 61
8' Voix Humaine 61
8' Trompette 61
4' Clarion 12
16' State Trumpet (TC) Great
8' State Trumpet Great
Zimblestern
Tremulant
Swell 16'
Swell Unison Off
Swell 4'
Positiv:
8' Principal from 4' Principal, 1-12=Great
8' Bourdon 61
4' Principal 61
4' Rohrflote 61
II Sesquialtera (TC) 98
2' Octave 61
1 1/3' Larigot 61
1' Sifflet 61
IV Cymbale 244
16' Cromorne 12
8' Trompete 12 ext. Great Bombarde 16'
8' Cromorne 61
8' State Trumpet Great
Tremulant
Positiv 16'
Positiv Unison Off
Swell to Positiv 16'
Swell to Positiv 8'
Swell to Positiv 4'
French Manual Transfer
Pedal:
32' Contre Bourdon from Subbass 16' 1-12=16' + 10 2/3'
32' Gedeckt Pommer from Pommer 16' 1-12=16' + 10 2/3'
16' Subbass 32
16' Pommer Great
16' Principal 32
8' Principal 12 ext. 16' Principal
8' Gedecktbass 12 ext. 16' Subbass
8' Pommer Great
8' Salicional Great
4' Choral Bass 32
4' Pommer Great
IV Mixture 68 derived from independent 2 2/3' = 2' ranks
32' Harmonics from Contra Posaune 16' 1-12=10 2/3' + 6 2/5' + 5 1/3' + 4 4/7' + 3 5/9' from Principal 16' and Subbass 16'
16' Bombarde Great
16' Posaune 32
16' Contre Hautbois Swell
8' Trompette Swell
8' Trompete 12 ext. Posaune 16'
4' Trompete 12 ext. Posaune 16'
4' Cromorne Positiv
8' State Trumpet Great
Great to Pedal 8'
Swell to Pedal 8'
Positiv to Pedal 8'
