Better Pipe Organ Database

Wicks Organ Co. Opus 4678 (1966)

Community United Church of Christ: Choir Loft
300 N Main St.
Morton, IL

Images

2022-11-22 - Organ and console. All pipes are located in the choir loft (Photograph by Michael Farney/Michael Farney)

Consoles

Main

Organ type: Traditional With Roll Top
Console position: Console in Fixed Position, Center
2 manuals
10 stops
46 registers
3 divisions
Key action Type: Electrical
Stop action Type: Electrical
Stop layout Type: Drawknobs in Vertical Rows on Angled Jambs
Manual compass: 61 notes
Pedal compass: 32 notes
Pedal Type: Concave Radiating (Details Unknown)
Expression Type: Balanced Expression Shoes/Pedals (Meeting AGO Standards)
Has crescendo
Combination action: Computerized/Digital
Syndyne LS2403K
Has combination thumb pistons
Has combination toe pistons
Has coupler thumb pistons
Has coupler toe pistons
Has tutti thumb pistons
Has tutti toe pistons

Notes

2022-11-28 - Updated status. Organ has been in regular and continuous use since its installation in 1966. -Michael Farney

Stoplist

Source: Taken from the Console 01/01/2023

SWELL (1966) (Pipes enclosed with shutters) Rohrflöte 8, Trompette 8, Salicional 8, Voix Celeste 8, Gemshorn 4, Nazard 2 ⅔ (SW Rohrflöte), Block Flöte 2 (SW Rohrflöte), Tierce 1⅗, Tremolo, Swell to Swell 16' Coupler, Swell Unison Coupler, Swell to Swell 4' Coupler

SWELL REPROGRAMMABLE STOPS (2007) (Reprogrammable on demand via Syndyne LS2403K control panel) Octave 2 (GT), Great to Swell 8' Coupler, Great to Swell 4' Coupler, Empty Empty

Great (1996) (Pipes exposed on and around swell chest) Principal 8, Gedeckt 8, Trompette 8 (SW), Gemshorn 8 (SW), Octave 4, Fifteenth 2, Mixture II (GT Fifteenth 8'+4'+2 2/3'), Chimes, Swell to Great 16' Coupler, Swell to Great 8' Coupler, Swell to Great 4' Coupler, Great to Great 4' Coupler

GREAT REPROGRAMMABLE STOPS (2007) (Reprogrammable on demand via Syndyne LS2403K control panel) Salicional 4 (SW), Rohrflöte 4 (SW), Great Unison Coupler, Great to Great 16' Coupler

PEDAL (1966) SubBass 16 (GT Gedeckt), Contra Trompette 16 (SW Trompette), Lieblich Gedeckt 16 (SW Rohrflöte), Trompette 8 (SW), Principal 8 (GT), Wald Flöte 8 (GT Gedeckt), Diapason 16 (GT Principal 16'), Choral Bass 4' (GT Principal 4'), Swell to Pedal 8' Coupler, Great to Pedal 8' Coupler

PEDAL REPROGRAMMABLE STOPS (2007) (Reprogrammable on demand via Syndyne LS2403K control panel) Trompette 4 (SW), Swell to Pedal 4' Coupler, Great to Pedal 4' Coupler, Empty Empty

Documents

(2022-11-24) Syndyne 2464 Combination Action Manual Syndyne 2464 controller board and programming for keys, stops, and pistons. -Michael Farney
(2022-11-23) Syndyne LS2403K Control Panel Manual Panel Installation, Panel Setup, Programming Stops/Couplers/Midi, Programmming Memory Levels, Setup Options, and Display Options -Michael Farney
(2022-11-23) Syndyne LS2400K Keying System Main Controller LS2400K Keying System Main Manual: system components, console wiring, console programming, chamber wiring, and chamber programming -Michael Farney
