2004-10-30 - Status Note: There 1996. -Database Manager
2004-10-30 - Cost $42,000. In 5 chambers. 10-rank Etherial/string div. (Nelson shows 387 reg.). Console on lift, stage right. -Database Manager
2007-08-09 - Updated through online information from Ralph W. Daniel. -- The Etherial division is located in a chamber on the upper section of the right (north) organ grille, not at the back of the auditorium or above the proscenium, as many rumors would have it. -Database Manager
2009-02-08 - Updated through online information from John Tanner. -- The 12 notes of the 32' Diaphones are installed in an area between the organ chambers and the interior walls of the auditorium. 6 pipes are installed on one side of the auditorium and 6 pipes on the other side. these pipes speak on 25" of wind. The 35 horsepower kinetic blower was replaced in the late 1980s with a new 70 horsepower Spencer Blower. Also a Baldwin player Grand piano was added in 1963. This piano was originally installed on the Kilgen organ in the Piccadily Theater, Chicago. -Database Manager
2021-11-17 - The console for "Mighty Mo" was rebuilt in 2020 by A. E. Schlueter Pipe Organ Company. During the original consoles removal a replica console, built by A. E. Schlueter Pipe Organ Company, was put in place to allow the organ to remain playable. A uniflex relay was put in place of the old Moller relay and combination action. All of the original machinery and parts have been retained and are in storage. No pipes were changed and no electronic voices were added to the instrument. There were some additional unifications and stop duplexes added to the console at the behest of the client. The present decorations on the reflect a careful study of what was under many layers of paint to restore the original look to the Fox console. -Arthur E. Schlueter III
2021-11-18 - The original console was rebuilt in 2020 by A. E. Schlueter Pipe Organ Company. During its renovation a replica console was in place.No stops changes. -Arthur E. Schlueter III
Typed Specification Source: from Factory Specification (April 26, 1929) Date not recorded
Atlanta, Georgia
Yaarab Temple A.C.O.N.M.S. / Fox Theatre
M. P. Möller, Inc. Opus 5566 1929 4 manuals, 42 ranks
__________________________________________________________________________________________________
LEFT SECTION RIGHT SECTION
CHAMBER "A" (lower) CHAMBER "C" (upper)
8' Chimney Flute 85 pipes 8' Stentorphone 73 pipes
8' Solo Violins III 255 pipes 16' Tibia Plena 85 pipes
8' Clarinet 73 pipes 16' Bourdon 97 pipes
8' Orchestral Oboe 73 pipes 16' Violoncello 97 pipes
8' Kinura 73 pipes 8' Violoncello Celeste 80 pipes
8' Minor Vox Humana 73 pipes 16' Harmonic Tuba 85 pipes
All Drums and Traps * 8' Saxaphone 73 pipes
Bass Drums I & II, Small Cymbals 8' English Horn 73 pipes
I & II, Castanets I & II, Triangles 4' Harp 61 bars
I & II, Tambourines I & II, Sleigh Xylophone 49 bars
Bells, Slap Sticks I & II, Wind
Effect I & II, Aeroplane Effect, CHAMBER "D" (lower)
Thunder Storm, Steamboat Whistle, 8' Solo Tibia Clausa 85 pipes
Locomotive Whistle, Snare Drums 8' Gemshorn 73 pipes
I & II, Chinese Block I & II, 8' Gemshorn Celeste 73 pipes
Chinese Gongs I & II, Sirens I & 8' Orchestral Violins III 255 pipes
II, Song Birds I & II, Ford Horn, 8' French Horn 73 pipes
Auto Horn, Door Bell, Chinese 8' Mezzo Vox Humana 73 pipes
Crash Cymbals I & II, Fire Gong, Chrysoglott 37 bars
Locomotive Bell, Ding Dongs I & II,
Shuffle
CHAMBER "B" (upper) ETHERIAL SECTION
16' Diaphonic Diapason 85 pipes CHAMBER "E" (duplex chest)
16' Tibia Clausa 97 pipes 8' Open Diapason 73 pipes
16' Viola 97 pipes 8' Dulciana 73 pipes
8' Gamba 85 pipes 8' Stopped Diapason 73 pipes
8' Gamba Celeste 85 pipes 4' Flute Harmonic 73 pipes
16' Solo Post Horn 85 pipes 8' Salicional 73 pipes
8' Post Horn 73 pipes 8' Vox Celeste (t.c) 61 pipes
8' French Trumpet 73 pipes 8' Small Trumpet 73 pipes
Marimba 49 bars 8' Oboe 73 pipes
Orchestral Bells 37 bars 8' Vox Humana 61 pipes
Chimes 25 tubes 16' Bourdon 44 pipes
32' Diaphone 12 pipes
(unenclosed; added 1985)
PEDAL GREAT SOLO
32' Acoustic Bass 16' Tibia Clausa 16' Tibia Clausa
16' Diaphone 16' Diaphone 16' Bourdon
16' Tibia Plena 16' Bourdon 16' String Bass 4 Rks
16' Tibia Clausa 16' String Bass 16' Tuba
16' Bourdon 16' Bass Viole 16' Bass Saxaphone (TenC)
16' String Bass 16' Gamba (TenC) 16' Vox Humanas 2 Rks
16' Bass Viole 16' Gamba Celeste (TenC) 16' Bass Clarinet
16' Tuba 16' Tuba 16' Bass Kinura
16' Solo Post Horn 16' Saxophone (TenC) 8' Diaphonic Diapason
8' Diaphonic Diapason 16' Clarinet (TenC) 8' Stentorphone
8' Stentorphone 16' Mezzo Vox Humana (TenC) 8' Tibia Plena
8' Flute 16' Vox Humana 8' Solo Tibia Clausa
8' Tibia Plena 8' Diaphonic Diapason 8' Tibia Clausa
8' Solo Tibia Clausa 8' Stentorphone 8' Concert Flute
8' Gambas 2 rks 8' Solo Tibia Clausa 8' Chimney Flute
8' Violoncellos 2 Rks 8' Tibia Plena 8' Gemshorn
8' Solo Violins 3 Rks 8' Tibia Clausa 8' Gemshorn Celeste
8' Clarinet 8' Concert Flute 8' Gamba
8' English Horn 8' Chimney Flute 8' Gamba Celeste
8' Tuba 8' Gemshorn 8' Violoncellos 2 Rks
4' Tibia Clausa 2 Rks 8' Gemshorn Celeste 8' Solo Violins 3 Rks
4' Gambas 8' Gamba 8' Orch. Violins 3 Rks
4' English Horn 8' Gamba Celeste 8' Tuba Harmonic
4' Solo Violins 3 Rks 8' Violoncellos 2 Rks 8' Solo Post Horn
4' Tuba 8' Viola 8' Post Horn
8' Solo Violins 3 Rks 8' French Trumpet
PEDAL 2ND TOUCH 8' Orch. Violins 3 Rks 8' Saxaphone
16' Diaphone 8' Tuba Harmonic 8' French Horn
16' Solo Post Horn 8' Solo Post Horn 8' English Horn
8' Tuba 8' Post Horn 8' Orchestral Oboe
Chimes 8' French Trumpet 8' Clarinet
First Bass Drum 8' Saxaphone 8' Kinura
Second Bass Drum 8' French Horn 8' Mezzo Vox Humana
First Cymbal 8' English Horn 8' Minor Vox Humana
Second Cymbal 8' Orchestral Oboe 4' Solo Tibia Clausa
Kettle Drum 8' Clarinet 4' Tibia Clausa
Snare Drum 8' Kinura 4' Tibia Plena
Persian Cymbals 8' Mezzo Vox Humana 4' Concert Flute
Chinese Gongs 8' Minor Vox Humana 4' Chimney Flute
4' Stentorphone 4' Gamba
ACCOMPANIMENT 4' Solo Tibia Clausa 4' Gamba Celeste
16' Bourdon 4' Tibia Clausa 4' Solo Violins 2 Rks
16' String Bass 4' Concert Flute 4' Orch. Violins 2 Rks
8' Diaphonic Diapason 4' Chimney Flute 4' Violoncellos 2 Rks
8' Stentorphone 4' Gambas 2 Rks 4' French Horn
8' Solo Tibia Clausa 4' Solo Violins 3 Rks 4' Kinura
8' Tibia Clausa 4' Orchestral Violins 4' Mezzo Vox Humana
8' Concert Flute 4' Solo Post Horn 4' Minor Vox Humana
8' Chimney Flute 4' French Trumpet 4' Clarinet
8' Gamba 4' French Horn 2 2/3' Solo Tibia Clausa
8' Gamba Celeste 4' Clarinet 2 2/3' Solo Violins 3 Rks
8' Gemshorn 4' Kinura 2' Solo Tibia Clausa
8' Gemshorn Celeste 4' Mezzo Vox Humana 2' Concert Flute
8' Violoncellos 2 Rks 4' Minor Vox Humana 2' Solo Violins 3 Rks
8' Viola 2 2/3' Tibia Clausa 1 1/7' Solo Tibia Clausa
8' Solo Violins 3 Rks 2 2/3' Nazard 1' Solo Tibia Clausa
8' Orch. Violins 3 Rks 2 2/3' Violoncellos 2 Rks 1' Solo Violins 3 Rks
8' Tuba 2' Tibia Clausa (4')Harp
8' Saxaphone 2' Concert Flute (8')Harp
8' French Horn 2' Solo Violins 3 Rks (4')Xylophone
8' English Horn 1 3/5' Tierce (2')Octave Xylophone
8' Orchestral Oboe (4')Harp Orchestral Bells (Repeat)
8' Clarinet (8')Harp Glockenspiel (Single)
8' Kinura (4')Xylophone Marimba (Repeat)
8' Mezzo Vox Humana (2')Octave Xylophone Marimbaphone (Single)
8' Minor Vox Humana Orchestral Bells (Repeat) Chrysoglott
4' Tibia Clausa Glockenspiel (Single) Chimes
4' Concert Flute Marimba (Repeat)
4' Violoncello Marimbaphone (Single) BOMBARDE
4' Viola Chrysoglott 16' Diaphone
4' Solo Violins 3 Rks Chimes 16' Brass Ensemble 5 Rks
4' French Horn ***** Etherial Section ***** 16' Flute Ensemble 2 Rks
4' Mezzo Vox Humana 8' Open Diapason 16' Strings 2 Rks (TenC)
2 2/3' Violoncello 8' Dulciana 16' Wood Wind Ens. 6 Rks (TC)
2' Concert Flute 8' Stopped Diapason 8' Diapasons 3 Rks
2' Violoncello 8' Salicional 8' Tibia Ensemble 3 Rks
2' Viola 8' Vox Celeste (TenC) 8' String Ensemble 8 Rks
1 3/5' Viola 4' Flute Harmonic 8' Brass Ensemble 6 Rks
(4')Harp 8' Small Trumpet 8' Wood Wind Ens. 7 Rks
(8')Harp 8' Oboe Vox Humana Chorus 7 Rks
(4')Xylophone 8' Vox Humana 4' Tibia Ensemble 3 Rks
(2')Octave Xylophone 4' Violins Ensemble 11 Rks
Orchestral Bells (Repeat) GREAT 2ND TOUCH 4' Wood Wind Ens. 6 Rks
Marimba (Repeat) 16' Diaphone 2' Tibias 2 Rks
Marimbaphone (Single) 16' Tuba 1' Fifes 3 Rks
Chrysoglott 16' Gamba (TenC) (4')Xylophone
Chimes 16' Gamba Celeste (TenC) Marimba (Repeat)
First Snare Drum (Roll) 16' Solo Post Horn Marimbaphone (Single)
First Snare Drum (Tap) 8' Diaphonic Diapason Orchestral Bells (Repeat)
Second Snare Drum (Roll) 8' Tibia Plena Glockenspiel (Single)
Second Snare Drum (Tap) 8' Solo Tibia Clausa Chrysoglott (Single)
Muffled Drum (Roll) 8' Gamba Chimes
Tom Tom 8' Gamba Celeste First Snare Drum (Roll)
Shuffle 8' Post Horns 2 Rks First Snare Drum (Tap)
Chinese Blocks (Roll) Glockenspiel (Single) Second Snare Drum (Roll)
Chinese Blocks (Tap) Snare Drums (Roll) Second Snare Drum (Tap)
Tambourines Solo to Great 8' Muffled Drum (Roll)
Castanets Solo to Great 4' Tom Tom
Shuffle
ACCOMPANIMENT 2ND TOUCH Chinese Blocks (Roll)
8' Diaphonic Diapason Chinese Blocks (Tap)
8' Tibia Plena Tambourine
8' Solo Tibia Clausa Castanets
8' Gamba ***** Etherial Section *****
8' Gamba Celeste 8' Open Diapason
8' Solo Violins 3 Rks 8' Dulciana
8' Orch. Violins 3 Rks 8' Stopped Diapason
8' Tuba 8' Salicional
8' English Horn 8' Vox Celeste (TenC)
8' Saxaphone 4' Flute Harmonic
8' French Horn 8' Small Trumpet
8' Clarinet 8' Oboe
Glockenspiel (Single) 8' Vox Humana
Chimes
Snare Drum (Roll)
Triangles
Song Birds
Solo to Accomp. 8'
Solo to Accomp. 4'
COUPLERS EFFECTS
Bombarde 4' Song Birds I (4 Birds) Triangle
Bombarde 2' Song Birds II (4 Birds) Persian Cymbals
Solo 4' Siren I (Megaphone) Chinese Gongs
Solo 16' Siren II (Megaphone) Grand Crash
Great 4' Ford Horn Cymbals (Small)
Solo to Great 16' Door Bell Grand Cymbals
Accompaniment 4' Slap Sticks Sleigh Bells
Accomp. to Great 8' Steamboat Whistle Wind Effect
Solo to Great 8' Auto Horn Storm (Thunder Roll)
Solo to Accomp. 8' Fire Gong Thunder Crash
Bombarde to Great 8' Locomotive Bell Chime Peal
Solo to Pedal 8' Locomotive Whistle Ding Dong I
Bombarde to Pedal 8' Aeroplane Effect Ding Dong II
Great to Pedal 8'
Accomp. to Pedal 8' ACCESSORIES
Pedal Octaves Locking slides to select Expression Pedals
Sforzando Piston under Great Manual
TRICK COUPLERS Trap Cancel Piston
Great to Solo 4 4/7' Vibrato Cancel Piston
Great to Solo 5 1/3' Coupler Cancel Piston
Great to Solo 6 2/5' 2nd Touch Cancel Piston
Drum Pistons ("On" and "Off")
TREMOLOS (VIBRATOS) Electric Piston for Operator's Booth
Orchestral A Electric Piston for Attendant
Orchestral B Red Light for Crescendo
Orchestral C National Light for Generator Test
Orchestral D Red & White Disk Indictors for Expression Pedals
Orchestral E Yellow Light for Harp Dampers when "On"
Foundation B Purple Light for Chime Dampers when "On"
Foundation C Voltmeter
Foundation D
Foundation E PEDALS
Lever for Chimes Dampers (reversible)
ADJUSTABLE COMBINATIONS Lever for Harp Dampers (reversible)
6 Bombarde & Ethereal * Sforzando Level (reversible)
6 Solo * Balanced Expression Pedal I
6 Great & Ethereal * Balanced Expression Pedal II
6 Accompaniment * Balanced Expression Pedal III (concaved smooth raw wood)
6 Pedal Balanced Expression Pedal IV
6 Entire Organ Balanced Expression Pedal V (Ethereal Organ)
* 2nd Touch affects Pedal Crescendo Pedal (cancels percussions & tremolos)
Balanced Mater Expression Pedal
[Received from Steven E. Lawson 2018-07-20]
