Better Pipe Organ Database

M. P. Möller Opus 9806 (1964)

St. John's Episcopal Church: sanctuary
705 Hale Road
Beverly Farms, MA

Consoles

Main

Organ type: Traditional With Roll Top
Console position: Console in Fixed Position, Center
3 manuals
52 stops
35 registers
6 divisions
Key action Type: Tubular Pneumatic (Details Unknown)
Stop action Type: Tubular Pneumatic (Details Unknown)
Stop layout Type: Drawknobs in Vertical Rows on Angled Jambs
Manual compass: 61 notes
Pedal compass: 32 notes
Pedal Type: Concave Radiating (Meeting AGO Standards)
Expression Type: Balanced Expression Shoes/Pedals (Meeting AGO Standards)
Combination action: Remote Pneumatic/Mechanical Capture
Has sequencer
Has combination thumb pistons
Has combination toe pistons
Has coupler thumb pistons
Has coupler toe pistons
Has tutti thumb pistons
Has tutti toe pistons

Notes

2007-10-24 - Identified through on-line information from don belben. -- The organ was primarily designed by the (late) noted consultant, Edward (Ned) Gammons of Groton School, Groton, Massachusetts. Its six divisions are: Great, Swell, Choir, Positiv, Antiphonal, and Pedal. In 1988 a French-styled Trumpet of solo nature, was added to the Choir division. -Database Manager

2009-05-18 - Updated through on-line information from Jeff Scofield. -Database Manager

2014-05-24 - Updated through online information from Mark Dirksen. -Database Manager

Stoplist

Stoplist copied from the factory specifications Source: Source not recorded Date not recorded

Beverly Farms, Massachusetts
St. John's Episcopal Church

Möller   Op. 9806   1964   3/48

       GREAT (3 1/4" wind)            SWELL (4")
   16' Rohrquintade 61             8' Principal 68
    8' Diapason 61                 8' Rohrgedeckt 68
    8' Holzflöte 61                8' Viola 68
    4' Octave 61                   8' Viola Celeste 61 GG
    4' Rohrflöte 24                4' Principal 12
    2' Waldflöte 61                4' Koppelflöte 68
   IV  Fourniture 244              2' Kleinflöte 12
       Sub                        IV  Plein Jeu 244
       Unison Off                 16' Basson-Hautbois 68 (1-18 L/2)
       Super                       8' Trompette 68
       Blank                       8' Hautbois 12
                                   4' Rohrschalmei 68
       CHOIR (4")                     Tremulant
    8' Rohrflöte 68                   Sub
    8' Gemshorn 68                    Unison Off
    8' Gemshorn Celeste 61 GG         Super
    4' Nachthorn 68
2 2/3' Nasard 61                      PEDAL (4")
    2' Blockflöte 61              32' Resultant --
1 3/5' Tierce 61                  16' Principal 32
    8' Cromorne 68                16' Sub Bass 32 (reg. Clarabella, wood)
       Tremulant                  16' Gemshorn 12 CH
    8' Trumpet 68 (6")            16' Rohrquintade GT
       (unenclosed)                8' Octave 12
       Sub                         8' Flöte 12
       Unison Off                  8' Gemshorn CH
       Super                       8' Rohrquintade GT
       Blank                       4' Choralbass 32
                                   4' Hohlflöte 12
       POSITIV (2 3/4")           IV  Mixture 128
    8' Nason Flute 61             16' Double Trumpet 12 CH (6")
    4' Flötenprinzipal 61         16' Basson SW
    2' Prinzipal 61                8' Trumpet CH
  III  Mixture 183                 4' Hautbois SW
                                      Blank
       ANTIPHONAL (3 1/2")
    8' Bordun 61
    4' Prestant 61
  III  Mixture 183

 [Received on line from Jeff Scofield May 18, 2009.]
