Cornel Zimmer Organ Builders Opus 112 (2011)

Trinity on the Hill United Methodist Church: Sanctuary
1330 Monte Sano Ave.
Augusta, GA

Images

2011-06-20 - "Sanctuary Interior, Chancel, and Pipe Facades" (Photograph by Jeff Scofield/Database Manager)

2011-06-20 - Chancel and Pipe Facades (Photograph by Jeff Scofield/Database Manager)

2011-06-20 - Console (Photograph by Jeff Scofield/Database Manager)

2011-06-20 - Church Exterior (Photograph by Jeff Scofield/Database Manager)

Consoles

Main

Organ type: Traditional Without Cover
Console position: Movable Console
3 manuals
4 divisions
Key action Type: Electrical
Stop action Type: Electrical
Stop layout Type: Drawknobs in Vertical Rows on Angled Jambs
Manual compass: 61 notes
Pedal compass: 32 notes
Pedal Type: Concave Radiating (Meeting AGO Standards)
Has crescendo
Combination action: Computerized/Digital
Has combination thumb pistons
Has combination toe pistons
Has coupler thumb pistons
Has coupler toe pistons
Has tutti thumb pistons
Has tutti toe pistons

Notes

2011-07-07 - Identified through on-line information from Jeff Scofield. -Database Manager

Stoplist

Stoplist from the console June 20, 2011 Source: Source not recorded Date not recorded

       Augusta, Georgia
       Trinity on the Hill United Methodist Church

       Cornel Zimmer   Op. 112   2011
       _______________________________________________

       No information given on the builder's
       website about what is pipe or digital

       GREAT                         SWELL
   16' Sub Principal             16' Lieblich Gedeckt
    8' Diapason                   8' Principal
    8' Harmonic Flute             8' Stopped Diapason
    8' Rohrflute                  8' Viole de Gambe
    8' Spitzprincipal             8' Viole Celeste
    4' Octave                     4' Italian Principal
    4' Hohlflute                  4' Koppelflute
2 2/3' Twelfth                2 2/3' Nazard
    2' Fifteenth                  2' Waldflute
   IV  Fourniture             1 3/5' Tierce
   16' Double Trumpet            IV  Plein Jeu
    8' Trumpet                   16' Fagotto
    8' Tuba             CH        8' Cornopean
    8' French Horn                8' Oboe
    4' Clarion                    8' English Horn
       Tremulant                     Tremulant
       Chimes                        Sub
       Zimbelstern                   Unison Off
                                     Super
       PEDAL
   32' Contra Bass                   ORCHESTRAL
   32' Contra Bourdon            16' Dulciana
   16' Open Wood                  8' Violoncello
   16' Principal                  8' Cello Celeste
   16' Sub Principal    GT        8' Bourdon
   16' Subbass                    8' Salicional
   16' Lieblich Gedeckt SW        8' Dulciana
   16' Dulciana         OR        8' Unda Maris
    8' Octave                     8' Flute Celeste II
    8' Bass Flute                 4' Principal
    8' Gemshorn                   4' Orchestral Flute
    4' Choralbass                 4' Gemshorn
    4' Nachthorn                  2' Piccolo
   32' Bombarde               1 1/3' Larigot
   16' Trombone                  II  Rauschquint
   16' Double Trumpet             8' Tuba
   16' Fagotto SW                 8' Clarinet
    8' Tromba                     8' Flugel Horn
    8' Tuba             CH           Tremulant
    8' Oboe             SW           Sub
    4' Clarion                       Unison Off
       Chimes                        Super
                                     Carillon

      [Received from Jeff Scofield  July 7, 2011]
